UHF Unity Gain Low Profile Antenna, 470-490MHz
The TLA400 is a low profile transmission line antenna ideal for applications with strict height requirements. The TLA400 delivers performance equivalent to a 3 wave whip, yet measures only 66mm tall. It’s rugged construction and low profile make it an ideal choice for industrial, rail and mining applications.
The TLA400 is a low profile transmission line antenna ideal for applications with strict height requirements. The TLA400 delivers performance equivalent to a 3 wave whip, yet measures only 66mm tall. It’s rugged construction and low profile make it an ideal choice for industrial, rail and mining applications.
Features:
- Low Profile – Only 66mm tall – ideal for height restricted applications
- Extremely Rugged – Cast aluminum construction
- Reliable – Fully pattern tested in verified range conditions
- Corrosion-resistant
- Fully interchangeable with existing products in the field
| Band | 470-490MHz |
| Tunable Bandwidth | Supplied in 20MHz bands @ <1.5:1 VSWR |
| Nominal Gain dBi | Unity over a ¼ wave |
| Power W | 100 |
| Whip Material | Rugged cast aluminum coated with baked enamel finish |
| Height mm | 66 |
| Termination | N-type Female |
| Shipping Weight (lbs.) | 3 |
| Shipping Dims (inches) | 13x7x7 |
